Architectural LED Lighting System

OrigamX Architectural LED Lighting

The OrigamX Architectural LED lighting system was developed for the world’s most creative Architects and most critical technical Lighting Designers to enable them to achieve the highest quality of light in the most diverse range of applications – including museums, high-end residential and retail.

The name OrigamX is a combination of Origami, the art of folding flat objects into alternate forms and structures, and “X” to highlight the technology.

OrigamX starts as a proprietary flat, flexible circuit card and is folded into a new form factor to create the most advanced LED light engine available today. Patented Hybrid Driver Circuitry provides unique DMX/RDM control features – including Ludicrous Mode, master dimmer, up to 16khz PWM, and incredibly smooth, theatrical grade dimming to 0%. Specifiers use an online configurator to select from tunable CCT, RGBA and RGBW LEDs, fixed or zoom optics and a range of housings and mounting options to fit their needs.

OrigamX Hub

OrigamX Power & Data Hub

The OrigamX Hub empowers electricians and contractors to provide power and data to remotely located OrigamX Architectural LED Lighting Fixtures for clean and simple installations in architectural, museum, and entertainment applications. Capable of powering and controlling up to 12 Modules, the OrigamX Hub utilizes a common CAT5e cable to deliver both low-voltage power and DMX signal to a Module located up to 240’ (73m) away from the Hub.

To connect OrigamX Light Fixtures to the Hub, simply plug the Hub into AC power and then connect it to a DMX control source using a 5-pin DMX cable. From there, connect up to 12 Modules to the output ports on the Hub using standard CAT5e Ethernet cables. The Hub has built in electrical safety features and features integral mounting points for ease of installation.

OrigamX Exploded View

Advanced Control Options
Patented Hybrid Driver Circuitry provides unique control features – including Ludicrous Mode, master dimmer control, up to 16khz PWM,adjustable total wattage (for LEEDs compliance) and incredibly smooth, theatrical grade dimming to 0%.

Ludicrous Mode
Increases brightness (up to 4x) of any color or CCT without sacrificing LED lifetime and enables tunable white light fixtures to operate at full power output at any CCT setting – eliminating the need to select a specific fixed color temperature in manufacturing.

Satisfied LDs and Architects
Modular design allows Lighting Designers, End Users and Architects/Interior Designers to collaborate on housing, mounting and lighting specs using an online application…not complicated data sheets and long SKUs.

Quality of Light
Proprietary binning, integral color calibration, the highest quality optics and cutting edge solid-state zoom option provides LDs with a next-generation tool for a variety of applications.

High Output. Tiny Package.
Ultra-compact, modular form factor uses Black Tank’s patented heat sink to provide a superior 16 watts and extended LED lifetime in a compact 2” diameter fixture.

DMX and 100% Compliant RDM
Black Tank’s theatrical grade dimming technology has been used on Broadway and in critical dynamic environments around the world.

Find Your OrigamX Representative

View the map below to find your closest sales representative.  If you are located outside of a territory please contact OrigamX directly.

OrigamX Tech Specs

Input Voltage12-24VDC
Power Consumption16W (DC Input) at 100% Output
Power InputCAT5 (Power +Data)
LEDRGBW / RGBA / Dynamic White
Lumen Maintenance80,000 hours B50 L70 at 45C (LM-79-08 Standard)
DataRJ45 Connector
Color Range4.2 billion discrete mixes (256 x 256 x 256 x 256)
OperationDMX: 8 or 16 bit DMX512
Operating Temp.-13° to 113° F (-20° to 45° C)
Humidity0 - 95% non-condensing
Weight8oz (0.23 kg)
ApprovalsFCC Class B Radiated and Conducted
ETL / UL Standards 2108
cETL / CSA C22.2 No. 250.0
UL8750 and CSA 250.13
CE / IP20 Rated

Click Here for More Info

OrigamX Contact Logo

Black Tank is a tech company focused on Architectural LED Lighting and theatrical grade product development. In partnership with Rosco Labs, we released the Cube Family which have been used around the world in Museums to light priceless art, critical theatrical environments such as Cirque De Soleil and on Broadway, and to replace traditional fixtures in dynamic architectural installations.
